POTENCIOMETRO 22K 3W LINEAL PE30LOFL223KAB

27,33 €
Impuestos incluidos
Cantidad
En Stock

Pagos 100% seguros
  • POTENTIOMETER, LINEAR, 22K, 3W, 10%
  • Track Resistance: 22kohm
  • Track Taper: Linear
  • No. of Turns: 1
  • Shaft Diameter: 6mm
  • Shaft Length - Metric: 25mm
  • Resistance Tolerance: ± 10%
  • Power Rating: 3W
  • Potentiometer Mounting: Panel
  • No. of Gangs: 1
  • Adjustment Type: Top
  • Body Diameter: 19.7mm
  • Contact Resistance Variation +: 3%
  • Electrical Angular Rotation Tolerance +: 10°
  • Electrical Angular Rotation Tolerance -: 10°
  • External Length / Height: 11.5mm
  • Full Power Rating Temperature: 70°C
  • Mechanical Angular Rotation Tolerance +: 5°
  • Mechanical Angular Rotation Tolerance -: 5°
  • Mounting Type: Panel
  • Operating Temperature Max: 125°C
  • Operating Temperature Min: -55°C
  • Operating Temperature Range: -55°C to +125°C
  • Proof Voltage: 2500V
  • Resistance: 22kohm
  • Resistor Element Material: Cermet
  • Rotation Electrical Angle: 270°
  • Rotation Mechanical Angle: 300°
  • Series: PE30
  • Temperature Coeff. +: 100ppm/°C
  • Temperature Coeff. -: 100ppm/°C
  • Temperature Coefficient: ± 100ppm/°C
  • Terminal Resistance Variation: 3%
  • Terminal Type: Solder Lug
