CD-DF410S DIODE, RECIFIC BRIDGE, 1 PHASE, 1KV, SMD

CD-DF410S is a CD-DF4xxS(L) series surface mount bridge rectifier diode. Bourns offers bridge rectifier diode for rectification applications in compact chip package 0.41" x 0.32" size format. Typical applications include AC operated products, computer monitors, set-top boxes and cable modems.
    Maximum repetitive peak reverse voltage is 1KV
    Maximum average forward rectified current is 4A
    Peak forward surge current 8.3ms is 150A
    Operating temperature range from -55 to +175°C
    Instantaneous forward voltage is 0.92V( IF = 2 A)
    Repetitive peak reverse current is 0.08µA
    Low power loss and high efficiency
    High current capability
    Low profile package

Núm. de Fases: Una Fase Corriente Directa Promedio: 4A Número de pinos: 4Pins Montaje de Puente Rectificador: Montaje en superficie Temperatura de Funcionamiento Máx.: 175°C Sustancia Extremadamente Preocupante (SVHC): Líder (25-jun-2025) Tensión inversa repetitiva máx.: 1kV Encapsulado del Puente Rectificador: SMD Tensión Directa Máxima: 950mV Sobrecorriente Directa: 150A
